Art of BI: OBIEE Workspace Integration Requires a Browser Plugin

By | In 11g, Art of BI, Big Data, Business Intelligence | October 28th, 2013

Oracle BI now has the ability to integrate with the well-known entry point for Oracle EPM, Workspace.  However, from a browser perspective this integration requires additional plug-in configuration on each user’s browser in order to render the interface correctly.  Some users already attempting this OBIEE to Workspace integration may have already seen an alert or notice to install a plug-in for their browser finding that the OBIEE Workspace Integration Requires a Browser Plugin.

The Oracle BI and Oracle EPM web-based interfaces are not certified with the Internet Explorer 10 browser version. We’ll address this in our upcoming OBIEE Infrastructure Series. That leaves IE versions < 10 and Firefox version 13+ as Firefox and Internet Explorer are the two most common browser standards in enterprise organizations. For companies standardizing on IE, Internet Explorer version 8 or 9 is the recommended browser for clients to achieve stable results with these GUI tools.

The details below provide guidance on how to install the necessary plugins for Internet Explorer < 10 and Firefox 13+ in order for Oracle EPM Workspace to function correctly.

On Firefox

You are prompted to install the Remote XUL Manager Add-On.


On Internet Explorer

You are prompted to install the Java SSV Plug-In.



Installing XUL on Firefox

For users to install and configure the XUL add-on:

  1. Install the Remote XUL Manager add-on from into Mozilla Firefox, and then restart Mozilla Firefox.
  2. In Mozilla Firefox, select Tools, then Web Developer, and then Remote XUL Manager to open the Remote XUL Manager dialog.
  3. In Remote XUL Manager, click Add…, and then add an entry for each host or domain name the EPM System Web server uses, then select File, and then select Close. For example, a typical deployment might have a test EPM System Web server at and a production server at The Remote XUL Manager can be configured with both host names ( and, or with just the domain name (for example, If the EPM System Web server is accessed using a short host name (for example, http://myserver/) or an IP address (for example,, add these names or IP addresses.


Enable on Internet Explorer

For users to install the Java Plug-In 2 SSV Helper plugin:

  1. Click the Enable button when prompted at the initial Workspace portal page.
  2. Install the plugin
  3. Restart the IE Browser

With the above configured you should now be able to access the OBIEE content in the Workspace portal as seen below:
