Where are your backups?

JP Chen | | June 1, 2016

As part of the SQL Server migration project planning, you need to find backup history to locate backup files, backup start date, backup finish date, duration required, and the backup size in MB. Let’s say that the Project Manager has requested you to present the backup duration in the format of HH:MM:SS so that she can make more close estimates on the time required for the migration. Unfortunately, SQL Server does not have built-in data columns to show you the backup duration in HH:MM:SS. In this blog, we will explore the required system tables, functions, and the techniques to create the backup history report requested.

We can find the backup details for each of the databases by querying the msdb.dbo.backupset and the msdb.dbo.backupmediafamily system tables. Here are the explanations of the system tables, functions, conversions, and case expressions that you need to know to get started:

  • DBO.BACKUPSET: This system table stores the information about the backup operations. It contains critical information such as the backup start date, backup end date, backup size, backup type, and other important backup details.
  • DBO.BACKUPMEDIAFAMILY: Contains one row for each media family. One of the most important data columns in this system table is the physical_device_name data column. It identifies the physical path of the backup.
  • CONVERT(): Converts an expression of one data type to another. Syntax: CONVERT ( data_type [ ( length ) ] , expression [ , style ] )
  • GETDATE(): Returns the current date and time on which the instance of SQL Server is running.
  • DATEADD(): Returns a specified date with the specified number interval added to a specified datepart of that date. Syntax: DATEADD (datepart , number , date )
  • DATEDIFF(): Returns the specified datepart boundaries between the start time and end time. Syntax: DATEDIFF ( datepart , startdate , enddate )
  • CASE EXPRESSION:Evaluates a list of conditions and returns one of the possible result expressions. In this blog, we will use the SIMPLE CASE expression.
  • REPLACE(): Replaces all occurrences of a specified string value with the replacement. Syntax: REPLACE ( string_expression , string_pattern , string_replacement )

Have you ever wondered how you can append the datetime stamp to the backup files without the “-“, “,“, “:”, “.”, and space? With the help of the built-in GETDATE(), REPLACE(), and CONVERT() system functions, you can. Here’s an example of how you can format the GETDATE() output to remove the space and exclude the special characters:

-- Removing the symbols and space from the default datetime

SELECT GETDATE() [Current DateTime], REPLACE(REPLACE(REPLACE(CONVERT(varchar, GETDATE(), 120), ':', ''), '-',''), ' ', '') [Current DateTime Removing the Symbols] --YYYYMMDDHHMMSS

Script: DateTimeMinusTheSpaceAndSymbols.sql

Output:

SQL Server does not have the built-in data column to show you the duration in the format of HH:MM:SS, but it does provide you the CONVERT() and DATEADD() system functions to get what you need. Here’s the script with examples to retrieve the duration in the desired format:

-- Display 120 seconds, 125.25 seconds, and 3600 seconds in the format of HH:MM:SS

SELECT CONVERT(varchar, DATEADD(ms, 120 * 1000, 0), 108) [2 minutes]

, CONVERT(varchar, DATEADD(ms, 125.25 * 1000, 0), 114) [2 minutes 5 seconds and 25 milliseconds]

, CONVERT(varchar, DATEADD(ms, 3600 * 1000, 0), 108) [1 hour]

Script: HHMMSS.sql

Output:

After reviewing and exploring the above code snippets that you can use to append the datetime stamp to the backup files and formatting the duration in HH:MM: SS, let’s now look into the scripts to run the full backups and check the backup history details.

Execute the following script to run the full backups. Modify it to select the databases you wish to backup and also to specify the backup folder within which you wish to store them:

-- Run the full backups for the selected databases with date and timestamp appended to the backup files
-- ****************************************************************************************************
-- Copyright © 2016 by JP Chen of DatAvail Corporation
-- This script is free for non-commercial purposes with no warranties.
-- ****************************************************************************************************
DECLARE DBFullBackups_Cursor Cursor
FOR
-- Pick the databases you wish to run full backups
SELECT db.name
FROM sys.databases db
WHERE db.name in ('AdventureWorks2012', 'AdventureWorksDW2012', 'Venti', 'Grande', 'Tall', 'TEST DB') -- Added [TEST DB] with space in the db name for testing purposes

OPEN DBFullBackups_Cursor
DECLARE @db varchar(125);
DECLARE @BackupPath varchar(225);
DECLARE @BackupCmd varchar(525);

-- Check to make sure the path exists
SET @BackupPath = 'E:\SQLBackup\' -- specify your own backup folder

FETCH NEXT FROM DBFullBackups_Cursor INTO @db
WHILE (@@FETCH_STATUS <> -1)
BEGIN
	-- Backup command
	SET @BackupCmd = 'BACKUP DATABASE [' +@db+ '] TO DISK = ''' +@BackupPath+@db+ '_'
	+REPLACE(REPLACE(REPLACE(CONVERT(varchar, GETDATE(), 120), ':', ''), '-',''), ' ', '') --YYYYMMDDHHMMSS
	+'.bak'''

	-- Print the backup command
	PRINT @BackupCmd

	-- Run the backup command
	EXEC (@BackupCmd)

	-- Fetch the next database
	FETCH NEXT FROM DBFullBackups_Cursor INTO @db
END

-- Close and deallocate the cursor
CLOSE DBFullBackups_Cursor
DEALLOCATE DBFullBackups_Cursor
GO

Script: FullBackups.sql

Screen-shot of the backup files:

After the backups are completed, you can run the following script to query the backup details. You can modify it to specify the past days to query for the backup history and also the databases returned. All the required data columns such as the recovery model of the databases, backup type, backup path, backup start date, backup finish date, backup duration in HH:MM:SS, and backup size in MB will also be included:

-- Where are your backups?

-- ****************************************************************************

-- Copyright © 2016 by JP Chen of DatAvail Corporation

-- This script is free for non-commercial purposes with no warranties.

-- ****************************************************************************

SELECT SERVERPROPERTY('SERVERNAME') as InstanceName

, bs.database_name as DatabaseName

, bs.recovery_model

, CASE bs.type

WHEN 'D' THEN 'Full'

WHEN 'I' THEN 'Differential'

WHEN 'L' THEN 'Log'

WHEN 'F' THEN 'File or Filegroup'

END as BackupType

, bmf.physical_device_name as BackupPath

, bs.backup_start_date as BackupStartDate

, bs.backup_finish_date as BackupFinishDate

, CONVERT(varchar, DATEADD(ms, DATEDIFF(second, bs.backup_start_date, bs.backup_finish_date) * 1000,0), 108) [Backup Duration HH:MM:SS] -- use 114 instead of 108 if you wish to see milliseconds

, CONVERT(NUMERIC (20,2), bs.backup_size/1024/1024) [Backup Size MB]

FROM msdb.dbo.backupset bs JOIN msdb.dbo.backupmediafamily bmf

ON bs.media_set_id = bmf.media_set_id

WHERE bs.backup_finish_date >= GETDATE() - 3 -- backups in the past 3 days

Script: WhereAreYourBackups.sql

Output:

As part of the database migration steps, the next step will usually require you to generate the database restore scripts and verify the database restores. We will explore these topics in a future blog.
