Q+A: Nulls and DASD

Recently, I received the following question, which I will answer today on this blog posting.

Question: Let’s say I have a table A which has 500 columns. Out of those 500 columns only 5 columns have been defined as not nullable and the rest have been defined as NULLS allowed. And out of those 500 columns I have found that 300 columns are unused (empty) totally. My business allows me to remove those 300 columns. My doubt is if I remove those 300 empty columns will I save on DASD space occupied by DB2? Will empty columns occupy DASD space? Would be really helpful if you can guide me on this.

Answer: I’m happy to try to help out. First of all, the short answer to your question is “Yes!” Those 500 columns are all consuming valuable disk space. To determine how much space is being consumed, you will need to examine the data type and length assigned to each column and add them up. And to make matters worse, you must add an additional 1 byte to each of them because the columns are nullable.

In DB2, a NULL is stored using a special one-byte null indicator that is “attached” to every nullable column. If the column is set to NULL, then the indicator field is used to record this. Using NULL will never save space in a DB2 database design – in fact, it will always add an extra byte for every column that can be NULL. The byte is used whether or not the column is actually set to NULL.

So, a column defined as CHAR(5) NOT NULL will required five bytes of storage space – but if it is defined as nullable, then it requires six bytes of storage space – five bytes for the data, and one byte for the null indicator.

Given all of this, it would seem that there is a very viable case to be made for you to remove those columns that are not being used. Of course, this means that you will likely have to make changes to any programs accessing that table. Because the table definition will change (fewer columns) you will need new DCLGENs and those will have to be included and bound into your programs. Be sure to factor this additional workload into your planning before moving forward with this change.

The better question to ask is “How the heck did all of the empty columns get put into the table to begin with and how did that design get past the DBAs?

If removing all of the columns proves to be too much of an administrative and programming burden, you can turn on compression for the table. With all of those columns being unused you should get a significant compression ratio thereby saving a lot of disk space.

This blog was originally published on Craig Mullins’ blog at: http://db2portal.blogspot.com/2008/03/qa-nulls-and-dasd.html

Craig Mullins
Consultant at Mullins Consulting, Inc
Craig S. Mullins is working with Datavail and its DB2 practice to expand offerings. He is president and principal consultant at Mullins Consulting, Inc. and the publisher of The Database Site. Mullins has 30 years of experience in all facets of database management and is the author of two books: “DB2 Developer’s Guide” currently in its 6th edition and “Database Administration: The Complete Guide to DBA Practices and Procedures,” the industry’s only guide to heterogeneous DBA.
