How to Resolve Systemd Issue with Percona XtraDB Cluster on CentOS 7

Author: Srinivasa Krishna | | January 18, 2017

Under CentOS 7, with the transition from System V to Systemd, Percona XtraDB Cluster was integrated with Systemd. As a result, Percona XtraDB cluster’s operation mode was split into two different scripts.

/usr/lib/systemd/system/mysql.service : Starts PXC with mysqld_safe, i.e. start/stop/restart a single node

/usr/lib/systemd/system/[email protected] : Passes an environment file to PXC which passes additional arguments (EXTRA_ARGS) to mysqld_safe. This script is used to bootstrap a node using the following command:

systemctl start [email protected]

This reads the file /etc/sysconfig/mysql.bootstrap and passes to mysqld_safe additional argument EXTRA_ARGS=" --wsrep-new-cluster ".



Systemd brings many advantages over its previous init systems, i.e. sysvinit, and upstart, including but not limited to: socket and D-Bus activation during startup; on-demand startup of services; aggressive parallelization capabilities; and many others. However, it presents an issue with the synchronization of nodes in PXC as discussed below.

PXC Issue with Systemd

PXC SST fails to sync the nodes, thus being unable to join cluster group and giving broken pipe 32 SIG errors on both xtrabackup-v2 and rsync methods. As indicated in the log’s error message on both donor and joining node, the ports are open and communicating well, and SST is working correctly.

On Donor Node

innobackup.backup.log

>> log scanned up to (15099371495026)

>> log scanned up to (15099371495026)

>> log scanned up to (15099371495026)

>> log scanned up to (15099371495026)

>> log scanned up to (15099371495026)

innobackupex: Error writing file 'UNOPENED' (Errcode: 32 - Broken pipe)

xb_stream_write_data() failed.

innobackupex: Error writing file 'UNOPENED' (Errcode: 32 - Broken pipe)

[01] xtrabackup: Error: xtrabackup_copy_datafile() failed.

[01] xtrabackup: Error: failed to copy datafile.

Backup Progress and Error log:

socat[9819] E write(3, 0xe79200, 8192): Broken pipe

donor: => Rate:[8.39MiB/s] Avg:[8.39MiB/s] Elapsed:2:28:31

WSREP_SST: [INFO] NOTE: donor-SST took 8912 seconds

WSREP_SST: [ERROR] innobackupex finished with error: 1. Check innobackup.backup.log

WSREP_SST: [ERROR] Cleanup after exit with status:22



On Joining Node

Log Entries:

joiner: => Rate:[1.83MiB/s] Avg:[6.88MiB/s] Elapsed:2:28:10 joiner: => Rate:[3.34MiB/s] Avg:[6.88MiB/s] Elapsed:2:28:20

WSREP_SST: [ERROR] Removing /.sst/xtrabackup_galera_info file due to signal

WSREP_SST: [ERROR] Cleanup after exit with status:143

[ERROR] WSREP: Process was aborted.

systemd: mysql.service: control process exited, code=exited status=2

mysqld_safe: 161115 20:46:15 mysqld_safe mysqld from pid file /b001/app/mysql/mysql.pid ended

mysql-systemd: WARNING: mysql pid file /b001/app/mysql/mysql.pid empty or not readable

mysql-systemd: WARNING: mysql may be already dead

systemd: Failed to start Percona XtraDB Cluster.

systemd: Unit mysql.service entered failed state.

systemd: mysql.service failed.



Explanation of the Problem

On Joining Node, during startup, SST is taking longer time to sync, therefore forcing startup script to fail. Unfortunately, the error message in the logs is misleading because it points to the broken pipe on SST streaming method. It can be noted that SST is mostly failing precisely at the same time in approximately 2 hours 28 minutes.

Solution

Check Systemd process and startup scripts for MySQL:

mysql systemd startup script (/usr/lib/systemd/system/mysql.service) has references for the timeout settings. Normally, you would not notice similar issues in Linux6.

Look for these variables and lines in /usr/bin/mysql-systemd

Variables:

service_startup_timeout=900 # Default

startup_sleep=1



Code:

while

[[ $i -lt $service_startup_timeout ]]



; do

….

….

if [[ $verb = 'created' ]];then

if ([[ -e $sst_progress_file ]] || grep -q -- '--wsrep-new-cluster' <<< "$env_args" ) \

&& [[ $startup_sleep -ne 10 ]];then

echo "State transfer in progress, setting sleep higher"

startup_sleep=10 #increments in 10sec based on SST progress.

fi

fi



i=$(( i+1 ))

sleep $startup_sleep



During SST transfer, the startup script will sleep for 10 seconds, effectively increasing timeout until it reaches the desired timeout value of 2 hours and 28 minutes. On slower networks, if you have multiple 100’s of gigabytes of data, it might take more time for SST to complete and these settings might not be sufficient. Depending on your dbsize, N/W bandwidth and how long it takes for SST to finish, increase these settings. During testing on a slower network with ~400G data, it took ~9 hours for SST to finish successfully.

This issue is not present in the older versions of Linux. Therefore, it can be deduced that if you are running PXC cluster on CentOS 7 with Systemd, it’s recommended to properly map references for timeout settings from multiple configuration files to resolve the Systemd issue with PXC cluster. Let’s hope the issue will be addressed in future releases.
